SmCo disc magnets

Round SmCo magnets

SmCo disc magnets are highly coercive magnets with high magnetic strength. SmCo disc magnets offers great resistance against corrosion and handles working temperatures up to 350 degrees Celcius. SmCo magnets are widely used for sensors, pumps or other devices where the magnet is required to operate at high temperatures.



  • All SmCo magnets are magnetized axially
  • Grade RSC26H is used producing the SmCo disc magnets
  • Max operating temperature: 350 °C
  • Tolerance Ø + H: +/- 0.1 mm
Specifications
Material: SmCo
Max temp.: 350 °C
Grade: RSC26H
Tolerance: +/- 0.1 mm
Magnetisation: Axially directed
Holding force: 10 Newton equals approx. to 1 kg.
Certifications: RoHS, REACH, Code of Conduct
100,00 kr
Models
Art. no. Ø mm H mm Holding force N Price Qty
6300 4 3 2,5
  • €1.43 from 10 pcs.
  • €1.16 from 100 pcs.
  • €0.85 from 1000 pcs.
  • €0.71 from 5000 pcs.
6310 5 3 3,5
  • €1.60 from 10 pcs.
  • €1.26 from 100 pcs.
  • €0.95 from 1000 pcs.
  • €0.82 from 5000 pcs.
6320 6 3 4
  • €1.77 from 10 pcs.
  • €1.39 from 100 pcs.
  • €1.02 from 1000 pcs.
  • €0.88 from 5000 pcs.
6360 10 3 10
  • €2.72 from 10 pcs.
  • €2.21 from 100 pcs.
  • €1.70 from 1000 pcs.
  • €1.46 from 5000 pcs.
6370 12 3 11
  • €3.54 from 10 pcs.
  • €2.72 from 100 pcs.
  • €2.14 from 1000 pcs.
  • €1.90 from 5000 pcs.
6390 15 3 18
  • €5.17 from 10 pcs.
  • €4.15 from 100 pcs.
  • €3.40 from 1000 pcs.
  • €3.10 from 5000 pcs.
6400 18 3 25
  • €7.89 from 10 pcs.
  • €6.53 from 100 pcs.
  • €4.76 from 1000 pcs.
  • €4.56 from 5000 pcs.
6410 24 3 30
  • €10.61 from 10 pcs.
  • €8.84 from 100 pcs.
  • €7.14 from 1000 pcs.
  • €7.04 from 5000 pcs.
Always 500000 magnets on stock as minimum
More than 20 years of experience. Custom-made magnets according to your needs
Certified magnets acc. to ROHS, REACH, EN71:3, Code of Conduct
Order before 2:00PM and we ship the same day
Need another dimension or magnet strength?
We develop individual magnet solutions for any need
Call +45 39 65 48 00
Or send us a message
Technical details
Product Description
Details

SmCo disc magnets are characterized as magnets that do not easily corrode and they generally speaking offer better corrosive conditions than for instance neodymium magnets. The cost of SmCo is relatively high due to the Cobalt thus restricting the use of the magnet to very special projects where no other magnetic type can be used as valid alternative.



The magnets can also be acquired as SmCo block magnets and SmCo ring magnets.



Remarks

*The holding forces have been determined at room temperature on a polished plate made of steel ( S235JR according to DIN 10 025) with a thickness of 10 mm by pulling the magnet vertically from the surface (1kg~10N). A deviation of -10 % (max.) in the stated values is possible in exceptional cases. In general, the value will be exceeded.

Specifications
Specifications
Material SmCo
Max temp. 350 °C
Grade RSC26H
Tolerance +/- 0.1 mm
Magnetisation Axially directed
Holding force 10 Newton equals approx. to 1 kg.
Certifications RoHS, REACH, Code of Conduct
Downloads
Additional information

All prices exclude vat.

Please note, that a handling fee of EUR 6 will be added to orders below EUR 65.
