Strong neodymium glass board magnets / round
Ideal for glass boards
Small strong neodymium magnets ideal for e.g. glass boards. The form of these magnets is round, no hole in the middle. They can hold many pieces of paper and documents and are easy to move around on the glass board. The strong magnets can be used in many different applications such as being incorporated in products, used as a hold function inside machines, inside magnetic knife racks etc. The list below contains magnets whose magnetic holding force are so strong that they can reach the metal backside through 4 mm thick tempered glass.
- Ideal for glass boards
- Possible to get a custom-made magnet
- Max temperature: 80 °C.
- Tolerance in diameter/height: +/- 0.1 mm
- See our complete range of Neodymium disc magnets here
Specifications
Material: Neodymium (NdFeb)
Surface: Ni-Cu-Ni
Max temperature: 80 °C
Grade: N35
Tolerance: +/- 0.1 mm
Holding force: 10 Newton ~ approx. 1 kg.
Certifications: RoHS, REACH, PAC free, Code of Conduct
100,00 kr
SIZES AND VARIANTS
| Art. no. | D mm | H mm | Holding force N | No. of A4 on a glass board | Antal A4 ark på glastavle | Price (Excl. VAT.) | Qty |
|---|---|---|---|---|---|---|---|
| 5270 | 8 | 4 | 15 | 1,5 | 1pc. |
| |
| 5281 | 8 | 10 | 21 | 2,1 | 3 pcs. |
| |
| 5310 | 10 | 5 | 18 | 1,8 | 2 pcs. |
| |
| 5310-1 | 10 | 6 | 19 | 1,9 | 2 pcs. |
| |
| 5310-8 | 10 | 12 | 34 | 3,5 | 6 pcs. |
| |
| 5311 | 12 | 3 | 18 | 1,8 | 3 pcs. |
| |
| 5312 | 13 | 2 | 13 | 1,3 | 2 pcs. |
| |
| 5314 | 14 | 12 | 62 | 6,3 | 17 pcs. |
| |
| 5315 | 15 | 8 | 56 | 5,7 | 11 pcs. |
| |
| 5317 | 18 | 2 | 17 | 1,7 | 5 pcs. |
| |
| 5318 | 18 | 4 | 36 | 3,7 | 13 pcs. |
| |
| 5319-N | 18 | 7 | 63 | 6,4 | 19 pcs. |
| |
| 5319-2 | 20 | 3 | 30 | 3,1 | 8 pcs. |
| |
| 5320 | 24 | 4 | 50 | 5,1 | 15 pcs. |
| |
| 5325 | 30 | 3 | 45 | 4,6 | 16 pcs. |
|
Always 500000 magnets on stock as minimum
More than 20 years of experience. Custom-made magnets according to your needs
Certified magnets acc. to ROHS, REACH, EN71:3, Code of Conduct
Order before 2:00PM and we ship the same day
Need another dimension or magnet strength?
We develop individual magnet solutions for any need
Call +45 39 65 48 00
Or send us a message
Technical details
Product Description
Details
A large selection of round strong neodymium magnets specifically for use on glass boards. See within the list how many pieces of paper the magnets can hold in the glass board.
We also produce by measures and are therefore able to custom-make glass board magnets after your needs and quantity. Please contact the sales department for more information.
See our full range of neodymium magnets here.
Specifications
Specifications
| Material | Neodymium (NdFeb) |
|---|---|
| Surface | Ni-Cu-Ni |
| Max temperature | 80 °C |
| Grade | N35 |
| Tolerance | +/- 0.1 mm |
| Holding force | 10 Newton ~ approx. 1 kg. |
| Certifications | RoHS, REACH, PAC free, Code of Conduct |
